| Name：Binger YC22 Waterproof,Bak4 porro prism,FMC optics Binoculars |
|
| Details： |
| Specification: |
|
|
|
|
| 产品系列 Product system |
YC22-6.5X32 |
YC22-10X42 |
YC22-12X50 |
| 产品型号 Product Type |
6.5X32 |
10X42 |
12X50 |
| 产品图片 Product picture |
|
| 放大倍率 Magnification |
6.5x |
10x |
12x |
| 颜色 Color |
GREEN |
| 物镜口径 Objective lens Ø |
32 |
42 |
50 |
| 出瞳直径 Exit pupil Ø |
4.9 |
4.2 |
| 出瞳距离 Exit pupil distance (mm) |
18 |
15 |
| 视场范围 Field of view (°) |
9.2° |
6.5° |
5.4° |
| 视场范围 Field of view (at 1000M) (m) |
161 |
114 |
95 |
| 视场范围 Field of view (at 1000yds) (ft) |
483 |
342 |
285 |
| 近焦距离 Near focus (m) |
3 |
4 |
7 |
| 视度系统 Diopter system |
Right diopter ring |
| 瞳距可调范围 Interpupillary distance(mm) |
50-74 |
| 调焦方式 Focus System |
Certer |
| 棱镜系统 Prism System |
Porro |
| 棱镜材料 Prism Glass Material |
Bak4 |
| 相对亮度Relative brightness |
24 |
18 |
18 |
| 黄昏指数Twilight factor |
14.4 |
20.5 |
24.5 |
| 屈光度Diopter compensation (dpt) |
±4 |
±6 |
| 光学组成 Optical Configuration |
物镜组成 Objective lens |
2E1G |
|
|
| 目镜组成 Ocular lens |
3E2G |
4E3G |
| 透镜镀膜Lens coating |
镀膜条件 Coating Condition |
Fully multi-coated on all air exposed lenses |
|
|
| 棱镜镀膜 prism coating |
入射面镀膜 Coating Condition |
Fully multi-coated on all air exposed lenses |
|
|
| 防水，防雾Water/Fogproof |
Yes |
| 眼杯类型 Eye cup |
类型 Type |
Fold down Eyecup |
| 目镜盖 eye caps |
类型 Type |
Yes |
| 物镜盖 obj. Cover |
类型 Type |
Yes |
| 适合三脚架 Adapt to tripod |
Yes |
| 肩带 strap |
Yes |
| 软包 soft case |
类型 Type |
Yes |
| 擦镜布 cleaning cloth |
Yes |
| 操作手册 instruction manual |
Yes |
| 包装 packaging |
10pcs a carton |
| 尺寸(长×宽×高) Size(Length×Width×Height) mm |
110x165x48 |
135x175x52 |
170x185x60 |
| 重量 Weight approx (g) |
520 |
620 |
740 |

| 产品系列 Product system |
YC22-0832 |
YC22-0842 |
YC22-1050 |
| 产品型号 Product Type |
8X32 |
8X42 |
1050 |
| 产品图片 Product picture |
 |
| 放大倍率 Magnification |
8x |
8x |
10x |
| 颜色 Color |
Green |
| 物镜口径 Objective lens Ø(mm) |
32 |
42 |
50 |
| 出瞳直径 Exit pupil Ø (mm) |
4 |
5.5 |
5 |
| 出瞳距离 Exit pupil distance (mm) |
15 |
18 |
18 |
| 视场范围 Field of view (°) |
8.1° |
7.5° |
6° |
| 视场范围 Field of view (at 1000M) (m) |
142 |
131 |
105 |
| 视场范围 Field of view (at 1000yds) (ft) |
425 |
393 |
315 |
| 近焦距离 Near focus (m) |
3 |
4 |
7 |
| 视度系统 Diopter system |
Right diopter ring |
| 瞳距可调范围 Interpupillary distance(mm) |
50-74 |
| 调焦方式 Focus System |
Certer |
| 棱镜系统 Prism System |
Porro |
| 棱镜材料 Prism Glass Material |
Bak4 |
| 相对亮度Relative brightness |
16 |
28 |
25 |
| 黄昏指数Twilight factor |
16 |
18.3 |
22.4 |
| 屈光度Diopter compensation (dpt) |
±6 |
±4 |
±4 |
| 光学组成 Optical Configuration |
物镜组成 Objective lens |
2E1G |
| 目镜组成 Ocular lens |
4E3G |
3E2G |
| Lens and prism coating |
Fully multi-coated on all air exposed lenses |
| 棱镜镀膜 prism coating |
入射面镀膜 Coating Condition |
Fully multi-coated on all air exposed lenses |
| 防水，防雾Water/Fogproof |
Yes |
| 眼杯类型 Eye cup |
类型 Type |
Fold down Eyecup |
| 目镜盖 eye caps |
类型 Type |
Yes |
| 物镜盖 obj. Cover |
类型 Type |
Yes |
| 适合三脚架 Adapt to tripod |
Yes |
| 肩带 strap |
Yes |
| 软包 soft case |
类型 Type |
Yes |
| 擦镜布 cleaning cloth |
Yes |
| 操作手册 instruction manual |
Yes |
| 包装 packaging |
10pcs a carton |
| 尺寸(长×宽×高) Size(Length×Width×Height) mm |
105x165x48 |
140x175x52 |
140x175x52 |
| 重量 Weight approx (g) |
520 |
620 |
620 |
| Description: |
|
|
|
|
| High quality custom High Performace porro prism binoculars Civil telescope Army green binocular telescope |
| There's no better value in binoculars than a pair of quality porro prisms. And we've taken porro prism performance |
| to a whole new level with a mid-size,wide-angle design featuring waterproof, fogproof construction and fully multi |
| fully multi-coated optics. The all-new 6.5x32 binocular delivers a bright, crisp image with excellent color fidelity |
| —even in low light conditions. With a wide range of interpupillary distance, this binocular can be easily adjusted |
| to fit anyone in the family, from young children to adults. |
|
|
|
Also, 8X32,8X42 and 10X50 available
| Features: |
|
|
|
|
| * Waterproof to protect the binocular in the harshest weather conditions or if accidentally submerged |
| underwater. |
|
|
|
|
| * Bak4 porro prism: Porro prism system provides greater depth perception and generally offer a wider field of |
| view and BAK4 material give higher quality glass, yielding brighter images and high edge sharpness |
| * FMC optics: Fully multi-coated lenses for maximum image brightness and contrast |
|
| * Classic design:Classic optical design for a long history and classic design with favorable price; |
|
| * Center focus system: Convenient centre-focus wheel for easy focusing |
|
|

|
|
|
|
|
